T type water filter

DN50-200mm
water filter is used to protect water meters or flow meters in pipelines from solid impurities, so that their measurement can operate normally.
Made of 304 stainless steel and funnel-shaped filter, it is convenient to clean impurities in the pipe network.
Conditions of use
◆Temperature grade: cold water T50 hot water T90
◆Water pressure grade: MAP10/16

Technical parameters WP-T type
Nominal diameter	DN	mm	50	65	80	100	125	150	200
length	L	mm	150	150	170	180	180	200	220
width	W	mm	165	185	200	220	250	285	340
high	H	mm	158	178	193	213	240	278	332
